Engineering Capabilities



TRUCON associates offer in-depth, multi disciplinary in the field of Transmission & microwave Tower. Further more through the decades of experience we provide extensive expertise in Design. Detailed engineering detailing and Shop drawing conversion, intelligent 3D space model as built engineering, Tower Design and substation Design.

Design of Transmission TowerDesign of Transmission Tower

  • Design of new Transmission line Tower as per client specification for 11 KV to 800 KV.
  • Design as per requirements of international standards like ASCE, IES, NESC, ASTM, DIN- VDE and Indian standards.
  • Checking the safety of existing Transmission line Towers for shield wire/conductor or replacements for specific site loading conditions.
  • Design and foundations of new Tower as per soil conditions and strengthening proposal for existing Tower foundations.
  • Preparation of sag template.
  • Preparation of Tower spotting .
  • Preparation of stringing chart.
  • Software we use: PLS-TOWER Tower matrix, autocad 2014, visual lisp,visual basic VB.NET, SQL Server2008 application software.

Design of Substation

  • Design of SubstationWith extensive engineering team we can Design and details electrical stations that deliver on line safety and efficiency in accordance with IS and International Standard.
  • Design and drawing of gantry (beams and coloumns).
  • Design of Equipment structure, Support Structure like CT,PI,CVT, Isolator Transformer etc.
  • Preparation of Raft foundation for Gantries and Equipment structures.
  • Preparation of Shop drawings for all Tower.
  • Automatic preparation of Bill Of Material from Shop drawing.
  • As built the project drawing/documentation.
  • Software we use: PLS-TOWER Tower matrix, autocad 2014, visual lisp,visual basic VB.NET, SQL Server2008 application software.

Details Drawings of Transmission Tower

  • Details Drawings of Transmission TowerDevelopment of detailed structural/Assembly drawings for new Transmission line Tower from 11KV to 800KV.
  • Tower detailing as per requirements of American Indian and British standards and accepted normal industrial practices.
  • Preparation of Shop drawings for all Tower members.
  • Preparation of detailed Bill Of Material for Tower.
  • Software we use: PLS-TOWER Tower matrix, autocad 2014, visual lisp,visual basic VB.NET, SQL Server2008 application software.

Drawing Microwave Tower

  • Drawing Mocrowave TowerDesign of new telecommunication Tower as per client requirements.
  • Design as per requirements of TIA/EIA Standards and Indian standard IS 875.
  • Tower detailing as per requirements of International standard like ASCE BS standards and accepted industry practicing.
  • Software we use: PLS-TOWER Tower matrix, autocad 2014, visual lisp,visual basic VB.NET, SQL Server2008 application software.
